BRAX DSP – Output Analog ESS
Features
- Exceptionally pure, authentic music reproduction with ultimate, outstanding sound quality thanks to the use of the latest and most modern component selections from the world’s leading-edge manufacturers
- Latest ultra advanced Analog Stereo Output Module for BRAX DSP featuring the latest flagship DAC model from ESS Technology, the ES9039Q2M
- ESS Technology ES9039Q2M is a high performance 32 Bit, 2-channel audio D/A converter with HyperStream IV Dual DAC technology and advanced SABRE HiFi architecture for unprecedented dynamic range and ultra-low distortion
- Analog signal path with the highest quality OpAmp in its class, the TI/BurrBrown OPA1612 with SoundPlus technology
- Power is supplied via an ingenious dual-supply concept in which each stereo channel has its own power supply
- 7 different, software-configurable digital FIR output filters with different characteristics for a perfectly fine-tuned audio experience
- Switchable output voltage of 2, 4 or 8 Volts for flexible connection options
- Display of all relevant measured values in the DSP PC-Tool (min. DSP PC-Tool V5.05 required)
Technical data
| Signal converter |
ESS Technology ES9039Q2M with HyperStream IV Dual DAC technology and advanced SABRE HiFi architecture |
| Operational amplifier | TI / BurrBrown OPA1612 with SoundPlus technology |
| Sampling rate |
192 kHz |
| Frequency response | 10 Hz – 80 kHz |
| Signal-to-noise ratio (A-weighted) | 130 dB |
| Total harmonic distortion (THD+N) | -116 dB (= 0.00015 %) |
| IM distortion (IMD) | -106 dB (= 0.0005 %) |
| Crosstalk | < -110 dB (@1 kHz) |
| Output voltage | 2 / 4 / 8 Volts RMS adjustable |
Compatibility
- BRAX DSP CORE model
Note: This module is only intended to be used for the initial installation of a BRAX DSP CORE model.
Scope of delivery
1 x analog output module with ESS converter
