Χαρακτηριστικά και Λειτουργίες

– 5-Channel, Class-AB Full Range Amplifier
– Stable into 4 ohms bridged or 2 ohms stereo load
– MOSFET power supply
– RCA and OEM speaker level input
– Variable Inputs Gain Control
– Variable FULL / LP / HP Electronic Crossover
– Variable Bass Boost

Τεχνικές Προδιαγραφές

– Power @ 4Ω: 4 x 70 + 1 x 250 watts
– Power @ 2Ω: 4 x 100 + 1 x 400 watts
– Power @ 4Ω Bridged: 2 x 180 + 1 x 400 (2Ω)
– THD @ Rated Power < 0.2%
– Signal to Noise Ratio > 90dB
– Channel separation > 45dB
– Frequency Response 10Hz to 30,000Hz ±1dB
– Input Sensitivity .25v to 5v
– Net Dimensions (mm): 182(W) x 52(H) x 351(L)
– Overall Dimensions (mm): 182(W) x 52(H) x 381(L)
